LPW5211
概述
The LPW5203 is an integrated power switch for self-powered and bus-powered Universal Series Bus applications. A built-in charge pump is used to drive the N-Channel MOSFET that is free of parasitic body diode to eliminate any reversed current flow across the switch when it is powered off. Its low quiescent current (30μA) and small package (SOT23-5) is particularly suitable in battery-powered portable equipment.
应用
◆Power Switch
◆USB Device
◆Battery Charger Circuits
◆USB Device
◆Battery Charger Circuits
数据参数
数据参数
输入电压 (V)
2.5~6
内阻(mΩ)
75
静态电流(uA)
30
输出电流(mA)
3000
FLAG指示
N
快速放电功能
N
通道数量
1
产品特征/功能
Low Rdson,SS,OTP
封装
SOT23-5
特征
特征
◆75mΩ Low RDS(ON), High-side N-MOSFET
◆2.5V to 6V Input Voltage
◆ Low Quiescent Current:30uA
◆Soft Start Function
◆Built-In Short-Circuit Protection
◆Built-in Thermal Protection
◆RoHS Compliant and 100% Lead(Pb)-Free
◆2.5V to 6V Input Voltage
◆ Low Quiescent Current:30uA
◆Soft Start Function
◆Built-In Short-Circuit Protection
◆Built-in Thermal Protection
◆RoHS Compliant and 100% Lead(Pb)-Free
